1 HALB

Eesti Põllumajandusülikool
Tehnikateaduskond
Mehaanika ja masinaõpetuse instituut

Enno Saks
Joonestuspakett AutoCAD 2000
(versioon 15.0)
II
Kolmemõõtmeline raalprojekteerimine
Programmeeritud joonestamine
Tartu 2000
1. Ruumilised koordinaadid
Ruumiliste jooniste valmistamiseks on vajalik tunda tähtsamaid ruumilisi koordinaatsüs-
teeme (vt joonis 1): ristkoordinaate xyz, silinderkoordinaate rz ja sfäärkoordinaate .
Silinderkoordinaatide saamiseks tuleb punkt P(x,y,z) projekteerida XY-tasandile, selleks on
joonisel 1 punkt P'(x,y,0). Punkti P' kaugus koordinaatide algusest O ongi parajasti polaar-
raadius r (r = x 2 + y 2 ), polaarnurk (0O < 360O , või ka ­180O < 180O ) on aga nurk
X-telje positiivse suuna ja polaarraadiuse vahel, kusjuures x = rcos , y = rsin .
Koordinaadid r ja on tavalised polaarkoordinaadid XY-tasapinnal. Sfäärkoordinaatide
puhul on suurus punkti P(x,y,z) kaugus koordinaatide algusest O ( = x 2 + y 2 + z 2 ). Nurk
määratakse siin samal viisil kui silinderkoordinaatide korral, aga vertikaaltasapinnas
mõõdetav nurk (­90O < 90O) määrab raadiuse kaldenurga XY-tasapinna suhtes.
Praktilisel joonestamisel pole ülaltoodud seoseid koordinaatide vahel vaja teada, küll aga
saab nurki ja kasutada jooniste vaatlemiseks suvalisest vaatesuunast (vt. punkt 5).

Joonis 1.
Ülalkirjeldatud rist-, silinder- ja sfäärkoordinaate saab kasutada punktide sisestamiseks
joonestamisel, näiteks (vt. ka lisa 1 juhendi esimesest osast):
· 8,13.5,-9 ­ absoluutsed ristkoordinaadid;
· @8,13.5,-9 ­ relatiivsed ristkoordinaadid;
· 7<22.5,6.45 ­ absoluutsed silinderkoordinaadid;
· @7<45,5.5 ­ relatiivsed silinderkoordinaadid;
· 4<90<30 ­ absoluutsed sfäärkoordinaadid;
· @4<90<30 ­ relatiivsed sfäärkoordinaadid.
Ruumiliseks joonestamiseks on edukalt kasutatavad ka mitmed juhendi esimeses osas
vaadeldud käsud. Selliste hulka kuulub näiteks käsk LINE ­ tuleb vaid kahe koordinaadi

2
asemel sisestada kolm koordinaati, nii nagu eespool kirjeldatud. Sama kehtib ka mitmete
teiste käskude kohta, näiteks RAY ja XLINE.
Seevastu käsuga PLINE ruumilist polüjoont joonestada ei saa, sest PLINE on ju tasapin-
naline objekt (moodustamise ajal paralleelne jooksva koordinaadistiku XY-tasapinnaga).
Küll aga saab kolmemõõtmelist polüjoont joonestada käsuga 3DPOLY, mis osutub kahe-
98% sisust ei kuvatud. Kogu dokumendi sisu näed kui laed faili alla
